Can you imagine if primary and secondary well control are failed? Well is flowing all the time so how can we deal with this situation? For this situation, you must use Tertiary Well Control.

Tertiary Well Control is specific method used to control well in case of failure of primary and secondary well control. These following examples are tertiary well control:

• Drill relief wells to hit adjacent well that is flowing and kill the well with heavy mud. Note: this case you can study from PTTEP Austraila Blow Out Incident. They use this method to control the well that was firing on the platform.
• Dynamic kill by rapidly pumping of heavy mud to control well with Equivalent Circulating Density (ECD)
• Pump barite or gunk to plug wellbore to stop flowing
• Pump cement to plug wellbore

Etc

Note: If you don’t want to miss any post from drillingformulas.com, please consider subscribing to our mail list. So you will not miss our posts.

Referring to the previous section, primary well control is hydrostatic pressure bore that prevents reservoir influx while performing drilling operations (drilling, tripping, running casing/completion, etc). When primary well control is failed, it causes kick (wellbore influx) coming into wellbore. Therefore, this situation needs special equipment which is called “Blow Out Preventer” or BOP to control kick.

Well, we can call that “Blow Out Preventer” or BOP is Secondary Well Control. Please also remember that BOP must be used with specific procedures to control kick such as driller method, wait and weight, lubricate and bleed and bull heading. Without well control practices for using BOP’s, it will just be only heavy equipment on the rig.

There are several types of “Blow Out Preventer” (BOP) which have different applications. I will talk about BOP categories later.

Note: If you don’t want to miss any post from drillingformulas.com, please consider subscribing to our mail list. So you will not miss our posts.

Love starts with your partner, children and family and expands to all world

God bless all mankind.

I wish you would have nice and safe year : )

Regards,

Rachain J.

Primary Well Control is hydrostatic pressure provided by drilling fluid more than formation pressure but less than fracture gradient while drilling. If hydrostatic pressure is less than reservoir pressure, reservoir fluid may influx into wellbore. This situation is called “Loss Primary Well Control”.

Not only is hydrostatic pressure more than formation pressure, but also hydrostatic pressure must not exceed fracture gradient. If your mud in hole is too heavy causing broken wellbore, you will face with loss circulation problem (may be partially lost or total lost circulation). When fluid is losing into formation, mud level in well bore will be decreased that will result in reducing hydrostatic pressure. In worst case scenario, you will lose the primary well control and wellbore influx or kill will enter into wellbore.

Typically, slightly overbalance of hydrostatic pressure over reservoir pressure is normally desired. You must keep in mind about the basic of maintaining primary well control that you must maintain hole with drilling fluid that will be heavy enough to overbalance formation pressure but not fracture formation.

Note: If you don’t want to miss any post from drillingformulas.com, please consider subscribing to our mail list. So you will not miss our posts.

For subsea applications, hydrostatic pressure exerted by the hydraulic fluid must be accounted for calculation.

In this case, we assume water depth at 1500 ft, therefore hydrostatic pressure exerted by hydraulic fluid (hydraulic fluid pressure gradient = 0.445 psi/ft) = 0.445×1500 = 668 psi. Besides of that, the concept for calculation is as same as surface accumulator. So please take a look about how to calculate usable volume per bottle as following steps.

Step 1 Adjust all pressures for the hydrostatic pressure of the hydraulic fluid:

Pre-charge pressure = 1000 psi + 668 psi = 1668 psi

Minimum system pressure = 1200 psi + 668 psi = 1868 psi

Operating pressure = 3000 psi + 668 psi = 3668 psi

Step 2 Determine hydraulic fluid required to increase pressure from pre-charge pressure to minimum system pressure:

Boyle’s Law for ideal gase: P1 V1 = P2 V2

1668 psi x 10 = 1868 x V2

16,680 ÷1,868 = V2

V2 = 8.93 gal

It means that N2 will be compressed from 10 gal to 8.93 gal in order to reach minimum operating pressure. Therefore, 1.07 gal (10.0 – 8.93 = 1.07 gal) of hydraulic fluid is used for compressing to minimum system pressure.

Step 3 Determine hydraulic required increasing pressure from pre-charge to operating pressure:

P1 V1 = P2 V2

1668 psi x 10 gal = 3668 psi x V2

16,680 ÷ 3668 = V2

V2 = 4.55 gal

It means that N2 will be compressed from 10 gal to 4.55 gal in order to reach operating pressure. Therefore, 5.45 gal (10.0 – 4.55 = 5.45 gal) of hydraulic fluid is used for compressing to operating pressure.

Step 4 Determine usable fluid volume per bottle:

Usable volume per bottle = Total hydraulic fluid/bottle – Dead hydraulic fluid/bottle

Usable volume per bottle = 5.45 – 1.07

Usable volume per bottle = 4.38 gallons

Ref: Formulas and Calculations for drill, production and workover by Norton J. Lapeyrouse

Note: If you don’t want to miss any post from drillingformulas.com, please consider subscribing to our mail list. So you will not miss our posts.

Accumulator (Koomey) is a unit used to hydraulically operate Rams BOP, Annular BOP, HCR and some hydraulic equipment. There are several of high pressure cylinders that store gas (in bladders) and hydraulic fluid or water under pressure for hydraulic activated systems. The primary purpose of this unit is to supply hydraulic power to the BOP stack in order to close/open BOP stack for both normal operational and emergency situation. Stored hydraulic in the system can provide hydraulic power to close BOP’s in well control operation, therefore, kick volume will be minimize. Accumulators should have sufficient volume to close/open all preventers and accumulator pressure must be maintained all time.

This post you will learn how to calculate usable volume per bottle by applying Boyle’s gas law:

Use following information as guideline for calculation:

Volume per bottle = 10 gal

Pre-charge pressure = 1000 psi

Operating pressure = 3000 psi

Minimum system pressure = 1200 psi

Pressure gradient of hydraulic fluid = 0.445 psi/ft

For surface application

Step 1 Determine hydraulic fluid required to increase pressure from pre-charge pressure to minimum:

Boyle’s Law for ideal gase: P1 V1 = P2 V2

P1 V1 = P2 V2

1000 psi x 10 gal = 1200 psi x V2

10,000 ÷ 1200 = V2

V2 = 8.3 gal

It means that N2 will be compressed from 10 gal to 8.3 gal in order to reach minimum operating pressure. Therefore, 1.7 gal (10.0 – 8.3 = 1.7 gal) of hydraulic fluid is used for compressing to minimum system pressure.

Step 2 Determine hydraulic required increasing pressure from pre-charge to operating pressure:

P1 V1 = P2 V2

1000 psi x 10 gals = 3000 psi x V2

10,000 ÷3000 = V2

V2= 3.3 gal

It means that N2 will be compressed from 10 gal to 3.3 gal. Therefore, 6.7 gal (10.0 – 3.3 = 6.7 gal) of hydraulic fluid is used for compressing to operating pressure.

Step 3 Determine usable fluid volume per bottle:

Usable volume per bottle = Hydraulic used to compress fluid to operating pressure – hydraulic volume used to compress fluid to minimum pressure

Usable volume per bottle = 6.7 – 1.7

Usable volume per bottle = 5.0 gallons

Ref: Formulas and Calculations for drill, production and workover by Norton J. Lapeyrouse

Note: If you don’t want to miss any post from drillingformulas.com, please consider subscribing to our mail list. So you will not miss our posts.

The last part of unit conversion is the conversion for  Pressure,Velocity, Volume and Weight specially used in the oilfield.

The RED number is the conversion unit.

Pressure

Atmospheres x 14.696 = Pounds/sq inch

Atmospheres x 1.033 = Kilograms/sq cm

Atmospheres x 101300 = Pascals

Kilograms/sq cm x 0.9678 = Atmospheres

Kilograms/sq cm x 14.223 = Pounds/sq inch

Kilograms/sq cm x 0.9678 = Atmospheres

Pounds/sq inch x 0.068 = Atmospheres

Pounds/sq inch x 0.0703 = Kilograms/sq cm

Pounds/sq inch x 0.006894 = Pascals

Velocity

Feet/sec x 0.305 = Meters/sec

Feet/mm x 0.00508 = Meters/sec

Meters/sec x 196.8 = Feet/mm

Meters/sec x 3.28 = Feet/sec

Volume

Barrels x 42 = Gallons

Cubic centimeters x 0.00003531 = Cubic feet

Cubic centimeters x 0.06102 = Cubic inches

Cubic centimeters x 0.000001 = Cubic meters

Cubic centimeters x 0.000264 = Gallons

Cubic centimeters x 0.001 = Litters

Cubic feet x 28320 = Cubic centimeters

Cubic feet x 1728 = Cubic inches

Cubic feet x 0.02832 = Cubic meters

Cubic feet x 7.48 = Gallons

Cubic feet x 28.32 = Litters

Cubic inches x 16.39 = Cubic centimeters

Cubic inches x 0.0005787 = Cubic feet

Cubic inches x 0.00001639 = Cubic meters

Cubic inches x 0.004329 = Gallons

Cubic inches x 0.01639 = Liters

Cubic meters x 1000000 = Cubic centimeters

Cubic meters x 35.31 = Cubic feet

Cubic meters x 264.2 = Gallons

Gallons x 0.0238 = Barrels

Gallons x 3785 = Cubic centimeters

Gallons x 0.1337 = Cubic feet

Gallons x 231 = Cubic inches

Gallons x 0.003785 = Cubic meters

Gallons x 3.785 = Liters

Weight

Pounds x 0.0004535 = Tons (metric)

Tons (metric) x 2205 = Pounds

Tons (metric) x 1000 = Kilograms

Note: If you don’t want to miss any post from drillingformulas.com, please consider subscribing to our mail list. So you will not miss our posts.

Ref book: Formulas and Calculations for drill, production and workover by Norton J. Lapeyrouse

The second part of unit conversion is the conversion for  Length,Mud Weight and Power specially used in the oil field.

The RED number is the conversion unit.

Length

Feet x 0.305 = Meters

Inches x 25.4 = Millimeters

Inches x 2.54 = Centimeters

Centimeters x 0.394 = Inches

Millimeters x 0.03937 = Inches

Meters x 3.281 = Feet

Mud Weight

Pounds/gallon x 7.48 = Pounds/cu ft

Pounds/gallon x 0.12 = Specific gravity

Pounds/gallon x 0.1198 = Grams/cu cm

Grams/cu cm x 8.347 = Pounds/gallon

Pounds/cu ft x 0.134 = Pounds/gallon

Specific gravity x 8.34 = Pounds/gallon

Power

Horsepower x 1.014 = Horsepower (metric)

Horsepower x 0.746 = Kilowatts

Horsepower x 550 = Foot-pounds/sec

Horsepower (metric) x 0.986 = Horsepower

Horsepower (metric) x 542.5 = Foot-pounds/sec

Kilowatts x 1.341 = Horsepower

Foot pounds/sec x 0.00181 = Horsepower

Ref book: Formulas and Calculations for drill, production and workover by Norton J. Lapeyrouse
