Trip Tank and Its Importance to Well Control

By | |
2 Comments

Trip tank is a small tank which has a capacity of 20 – 50 bbl and its shape is tall and shallow because it can effectively detect volume changes. The trip tank system has the ability to continuously fill the well and take return back to the tank. With this capability, it will keep the hole full all the time and the volume changes either increasing or decreasing can tell the condition of the well.

How The Trip Tank is Lined Up

The diagram (Figure 1) below demonstrates how the trip tank is lined up.

25 Trip Tank and Its Importance on Well Control 1

Figure 1 – Trip Tank Line Up To Continuously Fill The Hole

Continue reading →

Fatality Drilling Rig Accident, Oilfield Worker was Knocked 6 feet to the floor

By | |
Leave a comment

This is the oilfield incident resulting in our friend working on the rig got killed. It is very important that we need to heavily focus on the safety. Every year, people get injured due to several causes while working in the oilfield. For this case, there are several contributing factors the high pressure, line of fire, equipment inspection, etc. We want you to work safely for yourself and your family.

 land-rig

A high-pressure gate valve that came off a leaky standpipe on a Cyclone rig north of Parachute early in the evening of Oct. 21 struck and killed Shane Hill, 34, of Grand Junction and blew his body 6 feet away from the valve, a state report says.
Continue reading →

Know about Swabbing and Well Control

By | |
2 Comments

There are several situations when a kick is induced by swabbing effect. Today, we are going to discuss swabbing and well control situation. Swabbing is a condition when the string is pulled out of the well and it creates temporary bottom hole pressure reduction. If the hydrostatic pressure reduction is large enough to create underbalance condition, the well will eventually flow.

24-Know-abou-Swabbing-and-Well-Control-cover

When you swab the fluid in, the swabbed fluid may not necessarily cause pit gain or the well flowing because the volume swabbed in is not significant. However, if you have several swabbed-in fluid, the well will finally flow.

Figure 1 - Take Swabbed Kick

Figure 1 – Take Swabbed Kick

It is quite tricky to recognize the swabbing volume and the most trustable method to detect is by tracking hole fill volume. For example, if the volume displacement for 10 stands pulled is 8 bbl but the hole fill volume is just only 6 bbl, 2 bbls of kick may possibly be swabbed in while tripping out. Once the swabbing is detected, you need to trip back to the bottom and circulate bottom up even though the well is not flowing. If you don’t go back to the bottom, it will be very difficult to control the well off bottom once the swabbed gas moves up to shallower depth of the well. Continue reading →

17 Mind-Blowing Oil Drilling Rig Photos – Get Inspired For Oilfield People

By | |
1 Comment

Many people works on the oil rigs both offshore and onshore operation and a lot of people may get bored with the rig. Therefore we would like to share some spectacular drilling rig images. There are various rig types as land rig, shallow water rig, offshore deepwater rig, etc at various environment. At least, we wish these photos would inspire you 🙂

Please feel free to share with your friends and colleagues.

Rig Image 2

Continue reading →

Mud Gas Separator (Poor Boy Degasser) Plays A Vital Role in Well Control Situation

By | |
2 Comments

Mud gas separator located at downstream of the choke manifold is one of the important well control equipment that you need to focus. It separates gas out of the mud after the gas comes out of hole. Gas will be vent to atmosphere via the vent line in derrick (offshore operation) or the line away from the rigs (land operation) and the mud will be returned back to the pit.

In the oilfield, people have several names for the mud gas separator as “poor boy degasser” or “gas buster”. While drilling, the mud gas separator should be lined up at all times and filled with the present mud weight currently used.

mud-gas-seperator

The concept of this equipment is density difference between liquid and gas. When the mud coming out from the choke manifold goes into the mud gas separator, mud will hit the baffle plates which are used to increase travelling time and allow gas to move out of the mud. Gas which has lower density than air will move up and mud will goes down due to gravity (see – Figure 1). Mud leg will provide hydrostatic pressure in order to prevent mud going through the separator into the rig. Continue reading →
